Leuze HRT 96MP-1630-800-41-02 sensor specifications. Fork-type light grid, 30 beams, 800mm height, 16 PNP outputs, IP65, for high-resolution profiling.

Product Overview

The Leuze HRT 96MP-1630-800-41-02 is a high-resolution, fork-type light grid designed for detailed object profiling, height measurement, and sorting. It features 30 parallel infrared beams over an 800mm aperture height, providing 16 independent PNP transistor outputs. The sensor allows for grouping beams into up to 16 defined evaluation zones, enabling sophisticated object height classification and detection tasks in demanding industrial environments.

Technical Specifications

Key Features

• High Resolution (30 Beams):​ Enables precise object height profiling and sorting

• 16 Configurable PNP Outputs:​ Outputs can be assigned to individual beams or grouped into zones

• Large 800mm Aperture:​ Suitable for monitoring tall objects or wide conveyors

• Robust Aluminum Housing:​ Durable construction for industrial use

• IP65 Protection:​ Resistant to dust and water jets

• Flexible Configuration:​ Beam grouping and output assignment via DIP switches or teach-in

• M23 Connector:​ Secure, high-pin-count connection

• Integrated Alignment Aids:​ For fast and precise optical alignment

Applications

• Height verification and sorting of packages, pallets, or containers

• Object profiling and completeness checking

• Fill level control in large bins or on conveyors

• Break-in detection for large openings (non-safety rated)

• Logistics and material handling systems

Important Notes

1. This is a standard photoelectric light grid​ and is not a safety-rated device for personnel protection.

2. The 16 PNP outputs correspond to configurable evaluation zones, not necessarily to each of the 30 beams.

3. Configuration of beam groups and output logic is performed via DIP switches on the device.

4. A compatible M23, 25-pin connector cable must be purchased separately.

5. The sensor provides a detailed profile; object recognition is based on which beams are interrupted.
