SMC AC40A-04C-D Cylinder | Standard, 40mm Bore, 4mm Stroke, Double-acting, Compact, Cushion

SMC AC40A-04C-D Cylinder | Standard, 40mm Bore, 4mm Stroke, Double-acting, Compact, Cushion
SMC AC40A-04C-D Cylinder | Standard, 40mm Bore, 4mm Stroke, Double-acting, Compact, Cushion
video play

Large Image :  SMC AC40A-04C-D Cylinder | Standard, 40mm Bore, 4mm Stroke, Double-acting, Compact, Cushion Get Best Price

Product Details:
Place of Origin: CN
Brand Name: SMC
Certification: ATEX
Model Number: AC40A-04C-D
Document: ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: carton
Delivery Time: Negotiable
Payment Terms: T/T,XT,ALIPAY
Supply Ability: 100pcs per month
Contact Now
Detailed Product Description
Power Supply: 1 Ambient Temperature: -
Electrical Rating: G Certifications: S
Highlight:

SMC standard cylinder 40mm bore

,

double-acting compact cylinder 4mm stroke

,

SMC AC40A-04C-D cylinder with cushion

SMC AC40A-04C-D Cylinder | Standard, 40mm Bore, 4mm Stroke, Double-acting, Compact, Cushion

SMC AC40A-04C-D specifications. Standard pneumatic cylinder, 40mm bore, 4mm stroke, double-acting, with built-in cushion.

Product Overview

The SMC AC40A-04C-D is a compact, standard double-acting pneumatic cylinder from SMC's ACE series. It features a 40mm bore and a very short 4mm stroke. The cylinder is designed for precise, small-movement applications such as clamping, pressing, or positioning. It includes built-in cushioning at both ends to absorb impact and features a magnetic piston for easy integration with inductive sensors, making it suitable for automated systems requiring reliable short-stroke actuation.

Technical Specifications (Cylinder)

Parameter

Specification

Manufacturer​

SMC Corporation

Series​

ACE (Standard Air Cylinders)

Model​

AC40A-04C-D

Cylinder Type​

Double-acting, Single-rod

Piston Diameter (Bore)​

40 mm

Stroke Length​

4 mm

Cushioning​

Built-in cushion at both ends (adjustable)

Piston Position Sensing​

Magnetic piston (for use with magnetic sensors)

Rod End Thread​

Male thread (standard)

Technical Specifications (Performance/Mechanical)

Parameter

Specification

Operating Pressure​

0.05 to 1.0 MPa (0.5 to 10 bar)

Theoretical Force at 0.6 MPa​

754 N (advancing), 679 N (retracting)

Ambient/Media Temperature​

-10 to 60°C (14 to 140°F)

Operating Medium​

Clean, dry air (lubricated or non-lubricated)

Port Size​

Rc 1/8

Speed​

50 to 750 mm/s (with cushion)

Material, Barrel​

Aluminum alloy, hard anodized

Material, Piston Rod​

Stainless steel (SUS304)

Seals​

NBR (Nitrile)

Key Features

  • Ultra-Short 4mm Stroke:​ Designed for applications requiring minimal, precise linear movement

  • Double-Acting Operation:​ Provides controlled force in both extension and retraction

  • Built-in Cushioning:​ Reduces impact and noise at the end of the stroke

  • Magnetic Piston:​ Allows for non-contact position detection using a magnetic sensor

  • Compact Design:​ Saves space in machine layouts

  • Corrosion-Resistant Rod:​ Stainless steel piston rod for durability

  • Wide Pressure Range:​ Operates from 0.5 to 10 bar

  • Standard Ports:​ Rc 1/8 for easy pneumatic connection

Applications

  • Precision clamping and pressing operations

  • Small part ejection or positioning

  • Tool changers and fixture actuators

  • Gate control in molding or dispensing machines

  • Any automation task requiring a reliable, short-stroke linear actuator
