SMC VHS40-04-D Cylinder | Compact, 40mm Bore, 4mm Stroke, Double-acting, No Cushion, Guide

SMC VHS40-04-D Cylinder | Compact, 40mm Bore, 4mm Stroke, Double-acting, No Cushion, Guide
SMC VHS40-04-D Cylinder | Compact, 40mm Bore, 4mm Stroke, Double-acting, No Cushion, Guide SMC VHS40-04-D Cylinder | Compact, 40mm Bore, 4mm Stroke, Double-acting, No Cushion, Guide SMC VHS40-04-D Cylinder | Compact, 40mm Bore, 4mm Stroke, Double-acting, No Cushion, Guide

Large Image :  SMC VHS40-04-D Cylinder | Compact, 40mm Bore, 4mm Stroke, Double-acting, No Cushion, Guide Get Best Price

Product Details:
Place of Origin: CN
Brand Name: SMC
Certification: ATEX
Model Number: VHS40-04-D
Document: ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: carton
Delivery Time: Negotiable
Payment Terms: T/T,XT,ALIPAY
Supply Ability: 100pcs per month
Contact Now
Detailed Product Description
Power Supply: 1 Ambient Temperature: -
Electrical Rating: G Certifications: S
Highlight:

SMC VHS40-04-D compact cylinder

,

40mm bore double-acting cylinder

,

4mm stroke no cushion cylinder

SMC VHS40-04-D Cylinder | Compact, 40mm Bore, 4mm Stroke, Double-acting, No Cushion, Guide

SMC VHS40-04-D specifications. Compact pneumatic cylinder, 40mm bore, 4mm stroke, double-acting, no cushion, for precise short stroke.

Product Overview

The SMC VHS40-04-D is a compact, double-acting pneumatic cylinder from SMC's VH series. It features a 40mm bore and a very short 4mm stroke. Designed for applications requiring precise, small linear movements, this cylinder operates without built-in cushioning, making it suitable for rapid, repetitive short strokes. It includes a magnetic piston for position sensing and is known for its space-saving design, ideal for integration into jigs, fixtures, and compact automation equipment.

Technical Specifications (Cylinder)

Parameter

Specification

Manufacturer​

SMC Corporation

Series​

VH (Compact Air Cylinders)

Model​

VHS40-04-D

Cylinder Type​

Double-acting, Single-rod

Piston Diameter (Bore)​

40 mm

Stroke Length​

4 mm

Cushioning​

None (Non-cushioned)

Piston Position Sensing​

Magnetic piston (for use with magnetic sensors)

Rod End Thread​

Internal thread (for load attachment)

Technical Specifications (Performance/Mechanical)

Parameter

Specification

Operating Pressure​

0.05 to 1.0 MPa (0.5 to 10 bar)

Theoretical Force at 0.6 MPa​

754 N (advancing), 679 N (retracting)

Ambient/Media Temperature​

-10 to 60°C (14 to 140°F)

Operating Medium​

Clean, dry air (lubricated or non-lubricated)

Port Size​

M5 (metric)

Speed​

30 to 500 mm/s

Material, Barrel​

Aluminum alloy, hard anodized

Material, Piston Rod​

Stainless steel (SUS304)

Seals​

NBR (Nitrile)

Key Features

  • Ultra-Short 4mm Stroke:​ For precise, minimal linear movement applications

  • Compact Design:​ Space-saving profile ideal for tight installations

  • Double-Acting Operation:​ Provides controlled force in both directions

  • No Cushioning:​ Allows for very fast cycling in short-stroke applications

  • Magnetic Piston:​ Enables easy integration with magnetic reed or solid-state sensors

  • Lightweight & Durable:​ Hard-anodized aluminum body with stainless steel rod

  • Standard Metric Ports:​ M5 ports for connection

  • Internal Rod Thread:​ Facilitates direct attachment of tooling

Applications

  • Precision clamping, holding, and pressing in fixtures

  • Small part ejection and positioning

  • Actuation in compact assembly and testing equipment

  • Valve actuation and gate control

  • Any application requiring a reliable, fast-cycling, short-stroke actuator in a minimal space

SMC VHS40-04-D Cylinder | Compact, 40mm Bore, 4mm Stroke, Double-acting, No Cushion, Guide 0
