AUMA Z014.811A01 specifications. Worm gear set, 1:81.1 ratio, 5.5kW input, cast iron housing, for valve actuator drive.

Product Overview

The AUMA Z014.811A01 is a high-reduction worm gear set designed as a core component for AUMA electric multi-turn actuators. It provides a significant reduction ratio of 1:81.1, transforming high-speed motor input into the high-torque, low-speed output required to operate large industrial valves. The gear set features a robust cast iron housing, is lubricated for life, and is engineered for reliable, long-term service in demanding valve automation applications such as water supply, power generation, and process industries.

Technical Specifications (Gear Set)

Technical Specifications (Performance/Mechanical)

Key Features

• Very High Reduction Ratio (81.1:1):​ Provides extreme speed reduction and torque multiplication for large valves

• High Power Capacity:​ Rated for 5.5kW motor input, suitable for heavy-duty applications

• Robust Construction:​ Cast iron housing ensures maximum durability and load capacity

• Precision Gearing:​ For smooth, reliable operation and accurate positioning

• Maintenance-Free:​ Lifetime lubrication eliminates routine maintenance

• Core Actuator Component:​ Integral drive element within AUMA multi-turn actuators (e.g., SG series)

• Wide Temperature Range:​ Suitable for operation in extreme environments

• Engineered for Reliability:​ Designed for continuous, long-term service in critical applications

Applications

• Core drive component in high-torque AUMA multi-turn electric actuators

• Operation of large gate valves, sluice gates, and butterfly valves

• Water and wastewater treatment plants, dams, and large pipeline systems

• Power generation plants (thermal, hydro, nuclear) and heavy industrial processes
