Balluff BTL0HRF Transducer | Magnetostrictive, Linear, Analog, SSI, 0-1000mm, 24V DC, IP67

Balluff BTL0HRF Transducer | Magnetostrictive, Linear, Analog, SSI, 0-1000mm, 24V DC, IP67
Balluff BTL0HRF Transducer | Magnetostrictive, Linear, Analog, SSI, 0-1000mm, 24V DC, IP67 Balluff BTL0HRF Transducer | Magnetostrictive, Linear, Analog, SSI, 0-1000mm, 24V DC, IP67 Balluff BTL0HRF Transducer | Magnetostrictive, Linear, Analog, SSI, 0-1000mm, 24V DC, IP67 Balluff BTL0HRF Transducer | Magnetostrictive, Linear, Analog, SSI, 0-1000mm, 24V DC, IP67 Balluff BTL0HRF Transducer | Magnetostrictive, Linear, Analog, SSI, 0-1000mm, 24V DC, IP67

Large Image :  Balluff BTL0HRF Transducer | Magnetostrictive, Linear, Analog, SSI, 0-1000mm, 24V DC, IP67 Get Best Price

Product Details:
Place of Origin: DE
Brand Name: BALLUFF
Certification: ATEX
Model Number: BTL0HRF
Document: ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: carton
Delivery Time: Negotiable
Payment Terms: T/T,XT,ALIPAY
Supply Ability: 100pcs per month
Contact Now
Detailed Product Description
Power Supply: 1 Ambient Temperature: -
Electrical Rating: G Certifications: S
Highlight:

Balluff BTL0HRF magnetostrictive transducer

,

Linear transducer 0-1000mm range

,

Analog SSI transducer IP67 rated

Balluff BTL0HRF Transducer | Magnetostrictive, Linear, Analog, SSI, 0-1000mm, 24V DC, IP67

Balluff BTL0HRF specifications. Magnetostrictive linear position sensor, analog+SSI, 0-1000mm, 24V DC, IP67, for hydraulic cylinders.

Product Overview

The Balluff BTL0HRF is a high-precision magnetostrictive linear position sensor designed for demanding motion control applications. It provides both analog (4-20mA or 0-10V) and synchronous serial interface (SSI) outputs, allowing flexible integration. With a measuring range of 0-1000mm, 24V DC supply, and a robust IP67-rated stainless steel housing, it is ideal for precise, continuous position feedback in hydraulic and pneumatic cylinders, presses, and injection molding machines.

Technical Specifications (Sensor)

Parameter

Specification

Manufacturer​

Balluff GmbH

Series​

BTL (Magnetostrictive Position Sensors)

Model​

BTL0HRF (Configuration specific)

Product Type​

Magnetostrictive Linear Position Sensor

Measuring Principle​

Magnetostrictive, absolute

Measuring Range​

0 to 1000 mm (other ranges available)

Output Signals​

Analog (4-20mA or 0-10V) and SSI (synchronous serial interface)

Linearity Error​

≤ ±0.02% of full scale (typical)

Repeatability​

≤ ±0.001% of full scale

Technical Specifications (Electrical/Mechanical)

Parameter

Specification

Supply Voltage​

24V DC (10-30V DC)

Current Consumption​

≤ 60 mA

Resolution​

≤ 1 μm (analog), 0.1 μm (SSI)

Response Time​

≤ 1 ms (analog), configurable (SSI)

Housing Material​

Stainless steel (1.4305)

Process Connection​

M18 x 1.5 thread (standard)

Protection Rating​

IP67

Operating Temperature​

-40 to 85°C (-40 to 185°F)

Vibration/Shock Resistance​

High (suitable for industrial environments)

Certifications​

CE, cULus

Key Features

  • Dual Output (Analog + SSI):​ Offers flexibility for both simple and advanced control systems

  • Extreme Precision:​ High linearity and repeatability for closed-loop control

  • Robust Stainless Steel Housing:​ Resistant to pressure, vibration, and harsh media

  • Non-Contact Measurement:​ Wear-free, maintenance-free operation

  • Absolute Measurement:​ Provides position immediately upon power-up

  • High Resolution:​ Sub-micron resolution possible with SSI output

  • Wide Temperature Range:​ Operates reliably in extreme conditions

  • Easy Integration:​ Standard M18 mounting and electrical connections

Applications

  • Position feedback in hydraulic and pneumatic cylinders

  • Press and molding machine control

  • Valve position feedback

  • General industrial automation requiring high-accuracy linear position measurement
