Eaton 9SX1500 | 1500VA / 1350W Online UPS | 9SX Series

Eaton 9SX1500 | 1500VA / 1350W Online UPS | 9SX Series
Eaton 9SX1500 | 1500VA / 1350W Online UPS | 9SX Series Eaton 9SX1500 | 1500VA / 1350W Online UPS | 9SX Series Eaton 9SX1500 | 1500VA / 1350W Online UPS | 9SX Series Eaton 9SX1500 | 1500VA / 1350W Online UPS | 9SX Series

Large Image :  Eaton 9SX1500 | 1500VA / 1350W Online UPS | 9SX Series Get Best Price

Product Details:
Place of Origin: CN
Brand Name: Eaton
Certification: ATEX
Model Number: 9SX1500
Document: ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: carton
Delivery Time: Negotiable
Payment Terms: T/T,XT,ALIPAY
Supply Ability: 100pcs per month
Contact Now
Detailed Product Description
Power Supply: 1 Ambient Temperature: -
Electrical Rating: G Certifications: S
Highlight:

Eaton 9SX1500 UPS 1500VA

,

Online UPS 1350W

,

Eaton 9SX Series UPS

Eaton 9SX1500 | 1500VA / 1350W Online UPS | 9SX Series

Eaton 9SX1500 online double-conversion UPS. 1500VA / 1350W capacity, pure sine wave output, tower/rack-mountable, hot-swappable batteries, for server and industrial backup.

Product Overview

The Eaton 9SX1500​ is an online double-conversion UPS​ from the 9SX series​ with a rated capacity of 1500VA / 1350W. It provides true online power protection with zero transfer time, making it suitable for servers, network equipment, and industrial automation systems. This model features a graphical LCD display, hot-swappable battery modules, and supports optional external battery packs (EBMs) for extended runtime.

Technical Specifications (Electrical & Performance)

Parameter

Specification

Model / Series​

9SX1500​ (9SX Series)

Topology​

Online Double-Conversion​

Rated Capacity​

1500 VA / 1350 W​

Nominal Voltage​

200/208/220/230/240 V AC (Configurable)

Input Voltage Range​

190–276 V AC (No derating)

Output Waveform​

Pure Sine Wave​

Output Sockets​

6 × IEC C13 (10A)

Typical Runtime​

~5 min @ 100% load, ~13 min @ 50% load

Technical Specifications (Mechanical & Environmental)

Parameter

Specification

Form Factor​

Tower​ (Rack-mountable with kit)

Battery Type​

Sealed Lead-Acid (VRLA), Hot-swappable

Communication​

USB, RS-232, Relay Contacts, Optional SNMP/Modbus Card

Operating Temp.​

0 °C to +40 °C​

Dimensions (H×W×D)​

~252 × 160 × 437 mm

Weight​

~18.5 kg

Standards​

IEC/EN 62040-1, UL 1778, cULus, CE

Key Features

  • True Online Protection:​ Double-conversion technology provides complete isolation from grid noise, spikes, and frequency variations, ensuring clean power for sensitive electronics.

  • Extended Runtime Capability:​ Supports connection of up to 4 External Battery Modules (EBMs)​ to significantly increase backup time for critical applications.

  • Advanced Battery Management (ABM):​ Three-stage charging technology extends battery life and includes automatic self-test and temperature compensation.

  • Flexible Monitoring:​ Equipped with a graphical LCD interface and multiple communication ports (USB, RS-232, dry contacts) for integration with monitoring software and building management systems.

Applications

  • Server & IT Infrastructure:​ Protecting data centers, server rooms, and network closets from power outages and disturbances.

  • Industrial Automation:​ Providing backup power for PLCs, DCS systems, and process control equipment in manufacturing environments.

  • Critical Systems:​ Ensuring uninterrupted operation for security systems, medical devices, and communication equipment.
