6EP1334-2BA20 | SITOP PSU100S 24V DC 10A DIN Rail Power Supply, 120/230V AC Input

6EP1334-2BA20 | SITOP PSU100S 24V DC 10A DIN Rail Power Supply, 120/230V AC Input
6EP1334-2BA20 | SITOP PSU100S 24V DC 10A DIN Rail Power Supply, 120/230V AC Input 6EP1334-2BA20 | SITOP PSU100S 24V DC 10A DIN Rail Power Supply, 120/230V AC Input

Large Image :  6EP1334-2BA20 | SITOP PSU100S 24V DC 10A DIN Rail Power Supply, 120/230V AC Input Get Best Price

Product Details:
Place of Origin: RO
Certification: ATEX
Model Number: 6EP1333-2BA20
Document: ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: carton
Delivery Time: Negotiable
Payment Terms: T/T,XT,ALIPAY
Supply Ability: 100pcs per month
Contact Now
Detailed Product Description
Power Supply: 1 Ambient Temperature: -
Electrical Rating: G Certifications: S
Highlight:

SITOP PSU100S 24V DC power supply

,

DIN rail power supply 10A

,

120/230V AC input power supply

6EP1334-2BA20 | SITOP PSU100S 24V DC 10A DIN Rail Power Supply, 120/230V AC Input
6EP1334-2BA20 SITOP PSU100S switched-mode DIN rail power supply — 24 V DC 10 A (240 W), 1-phase 120/230 V AC auto-ranging input, adjustable 22.8–28 V, IP20, screw terminals

Product Overview

6EP1334-2BA20​ is a SITOP PSU100S single-phase switched-mode power supply​ delivering 24 V DC at 10 A (240 W nominal output). It features wide-range input (85–132 V AC / 170–264 V AC, auto-select), an adjustable output voltage of 22.8–28 V DC​ via front potentiometer, and provides 120% continuous overload capability up to 45 °C​ plus 150% power boost for 5 s. The unit mounts on a standard 35 mm DIN rail, uses screw-type terminals​ for input/output/PE, includes a DC OK green LED and floating N/O contact​ for remote monitoring, and is convection-cooled (no fan). Compatible with SITOP buffer, redundancy, and DC-UPS extension modules.

Technical Specifications (Input & Output)

Parameter
Specification
Order Number​
6EP1334-2BA20​ (SITOP PSU100S 24 V / 10 A)
Input Voltage (Rated)​
1 × AC 120 V / 230 V (50/60 Hz), auto-ranging​
Input Voltage Range​
AC 85–132 V / 170–264 V
Nominal Input Current​
~1.9 A @ 230 V AC / ~4.1 A @ 120 V AC (full load)
Output Voltage (Rated)​
DC 24 V​ (adjustable 22.8–28 V via front pot)
Rated Output Current​
10 A​ @ 24 V DC (240 W)
Overload Capability​
120% continuous (≤45 °C); 150% for 5 s (start-up surge)
Ripple & Noise (typ.)​
≤ 150 mV pk-pk
Efficiency (typ. @ 230 V)​
≈ 90 %​
Power Loss (typ. @ full load)​
≈ 25 W

Technical Specifications (Mechanical & Environmental)

Parameter
Specification
Number of Outputs​
1 (floating, SELV)
Terminals​
Screw-type: L/N/PE (input), +/− (output), signalling contact (2×) — 0.5–2.5 mm²
Mounting​
35 mm DIN Rail (EN 60715 / TS 35)​ — snap-on
Dimensions (H × W × D)​
125 × 70 × 120 mm​
Weight (Approx.)​
0.75 kg
Degree of Protection​
IP20​ (installed in enclosure)
Operating Temp. Range​
-25 … +70 °C​ (derating 3%/K above 60 °C)
Signalling​
Green LED (DC OK) + floating N/O relay contact (30 V DC / 1 A, 60 V DC / 0.3 A)
MTBF @ 40 °C​
≈ 1,600,000 h
Certifications​
CE, cULus (UL 508 / CSA C22.2 No.107.1), GL (DNV GL), IEC 60950-1 / EN 50178, Class I Div 2
EMC Emission​
EN 55022 Class B (residential & industrial)

Key Features

  • Extra Power Boost (150%):​ Briefly supplies up to 15 A for inrush or motor starting loads without tripping.
  • 120% Continuous Overload:​ Maintains 12 A output up to 45 °C — accommodates panel expansion without upsizing.
  • Adjustable Output (22.8–28 V):​ Compensates for voltage drop in long DC feeder cables.
  • DC OK Signal Contact + LED:​ Easy integration into PLC/machine fault monitoring — detects output failure or pre-alarm.
  • SITOP Extension Ready:​ Snap-on buffer (BUFFER MODULE 24V/20A), redundancy (RED1200), or DC-UPS modules mount directly beside it.

Typical Applications

  • Control Cabinet Primary Supply:​ Powers PLCs, I/O modules, sensors, relays, and small DC actuators in machine control panels.
  • Conveyor / Packaging OEM:​ Compact 70 mm width leaves DIN rail space for breakers, relays, and terminal blocks.
  • Process Skids & Test Benches:​ Where 24 V DC is required from single-phase mains with basic diagnostics.
  • Retrofit Projects:​ Replaces older linear supplies or lower-efficiency SMPS — same DIN footprint, better overload behavior.
If you actually needed the 5A version (6EP1333-2BA20): 24V/5A, 50 mm width, same input spec — let me know and I'll swap it. The 10A unit here is 6EP1334-2BA20.
