6ES7336-4GE00-0AB0 | SIMATIC S7-300 SM 336 F-DI 6× Safety Input Module

6ES7336-4GE00-0AB0 | SIMATIC S7-300 SM 336 F-DI 6× Safety Input Module
6ES7336-4GE00-0AB0 | SIMATIC S7-300 SM 336 F-DI 6× Safety Input Module 6ES7336-4GE00-0AB0 | SIMATIC S7-300 SM 336 F-DI 6× Safety Input Module

Large Image :  6ES7336-4GE00-0AB0 | SIMATIC S7-300 SM 336 F-DI 6× Safety Input Module Get Best Price

Product Details:
Place of Origin: DE
Certification: ATEX
Model Number: 6ES7 336-4GE00-0AB0
Document: ACH-AB-P+F-E+H-IFM-ASCO-YOK...WA.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: carton
Delivery Time: Negotiable
Payment Terms: T/T,XT,ALIPAY
Supply Ability: 100pcs per month
Contact Now
Detailed Product Description
Power Supply: 1 Ambient Temperature: -
Electrical Rating: G Certifications: S

6ES7336-4GE00-0AB0 | SIMATIC S7-300 SM 336 F-DI 6× Safety Input Module
6ES7336-4GE00-0AB0 SIMATIC S7-300 SM 336 F-DI 6× safety digital input module. 6 failsafe inputs, 24V DC, Category 4 / SIL 3 / PL e, for Fail-Safe CPU 31xF.

Product Overview

The 6ES7336-4GE00-0AB0​ (Order No. 6ES7336-4GE00-0AB0) is a Failsafe Digital Input Module (SM 336 F-DI 6×)​ for the SIMATIC S7-300​ programmable logic controller system. It provides six isolated safety-certified digital inputs (24 V DC)​ designed for connection to emergency stop buttons, safety mats, light curtains, and safety interlock switches. The module is intended for use with S7-300F (Fail-Safe) CPUs​ and supports evaluation up to Category 4 / SIL 3 / PL e​ per EN ISO 13849-1 and IEC 61508.

Technical Specifications (Electrical & I/O)

Parameter
Specification
Order Number​
6ES7336-4GE00-0AB0​
Product Series​
SIMATIC S7-300 — SM 336 F-DI 6×
Number of Inputs​
6 × Failsafe Digital Inputs (DI)​
Input Voltage (Nominal)​
24 V DC​ (Type 1, per IEC 61131-2)
Input Delay (Programmable)​
0.1 ms … 75 ms (typical for debounce/time-stamping)
Input Current (Per Channel)​
Typ. 7 mA @ 24 V DC
Cable Length (Unshielded/Shielded)​
Max. 600 m (shielded), 300 m (unshielded)
Safety Integrity Level​
SIL 3​ (IEC 61508) / Category 4 / PL e​ (EN ISO 13849-1)
Test Pulse Evaluation​
Integrated — detects cross-circuit and wire break

Technical Specifications (Mechanical & Environmental)

Parameter
Specification
Module Width​
40 mm​ (Standard S7-300 single-width)
Backplane Bus​
IM 360 / IM 361 / Direct to CPU Rack​ (Rack 0–3)
Power Consumption (from Backplane)​
Typ. 0.8 W (logic) + 0.6 W (inputs)
Connection Type​
**Screw / Spring Clamp (Front Connector 40-pin — ordered separately: 6ES7392-1...)
Operating Temperature​
0 … +60 °C​ (Horizontal), 0 … +40 °C (Vertical in enclosed rack)
Protection Rating​
IP20 (Cabinet Mount)
Certifications​
CE, UL, FM, GL, DNV, ABS, TÜV (SIL 3 / Cat. 4 / PL e)

Key Features

  • Failsafe Input Processing:​ Each input is continuously tested by the CPU's F-runtime group — any discrepancy (wire break, cross-short, stuck contact) forces a safe state (0) on the associated F-tag.
  • Direct S7-300F Compatibility:​ Works exclusively with CPU 315F-2 DP/PNG, CPU 317F-2 PN/DP​ and similar F-CPUs — not usable in standard (non-failsafe) S7-300 racks for safety functions.
  • Flexible Wiring:​ Accepts standard 1× / 2× wiring per IEC 61131-2 Type 1 sensors (NPN sourcing to 0V / PNP sinking to 24V — wiring diagram in manual).
  • Diagnostics & LED Indication:​ Per-channel status LEDs + module-level SF (System Fault) and F (Failsafe Active) LEDs simplify troubleshooting.

Applications

  • Emergency Stop & Guard Monitoring:​ Reading E-STOP N/C contacts and safety gate interlock N/C contacts into the safety program.
  • Safety Light Curtain / Mat Integration:​ Connecting OSSD outputs from light curtains or safety mats to the F-DI module.
  • Process Safety Instrumented Functions (SIF):​ Bringing field-mounted safety sensors (vibration, overtravel, temperature trip) into the SIL 3-rated safety logic.
Note: Front connector (40-pin, screw or spring) must be ordered separately — e.g., 6ES7392-1AM00-0AA0​ (screw) or 6ES7392-1BM01-0AA0​ (spring). The SM 336 F-DI 6× occupies one slot in the S7-300 rack and requires the F-CPU to execute safety logic. For 16-channel F-DI, see 6ES7336-4GG00-0AB0.
